Cable Type BY3

CR-3100/3200 Y Cable

Cash Drawer to Viaduct Serial Connection

(Connect to Viaduct

Serial Cable)

PC RS232

9 pin 9 Pin

D Type D Type

Female Male

Shield

1 White/Orange 1

2 White/Blue 2

3 Green 3

4 White/Green 4

5 Blue 5

6 Orange 6

7 Brown 7

8 White/Brown 8

25CM

2M Cash Drawer

9 Pin

D Type

Female

3

5

NOTE: Cable BY3 must be FTP (Foil Screened Twisted Pair)

		Revision 15
	NOTE: Maximum length 2 ft
Amendment 15
